DETAILS
Applications
* With liquid-filled case for applications with high dynamic pressure pulsations or vibration
* Suitable for corrosive environments and gaseous or liquid media that will not obstruct the pressure system
* Process industry: chemical / petrochemical, power stations, mining, on and offshore, environmental technology, mechanical engineering and plant construction
Features
* Design EN 837-1
* Dial: 1.5”(40mm), 2”(50mm), 2.5"(63mm), 3"(80mm), 4"(100mm) and 6"(160mm)
white aluminium dials with black and red markings
* Case: 304 stainless steel
* Range: Normal: 0…0.6bar to 0…1000bar
Vacuum: -76cmHg…0
Compound: -76cmHg..0…35bar
Scale: bar, psi, kg/cm2, kPa, MPa, etc.
* Connection: 1/8”,1/4”, 3/8”,1/2” NPT, BSP, BSPT,etc.
* Window: Polycarbonate window, armored glass or safety glass
* Pointer: Black aluminium, fixed or adjustable
* Bourdon tube: 304 or 316 stainless steel
* Socket:: 304, 316 or 316L stainless steel
* Glycerine-filled, silicon-filled or dry with filling hole
* Crimp ring or bayonet bezel
* Restrictor in connection
Accuracy class
* 1.5", 2" : ± 2.0%
* 2.5" & 3": ± 1.6%
* 4" & 6”: ± 1.0%
* Please indicate the parameter when you send an inquiry.
Product Specifications
Company Profile
Our Certifications
Our Advantages
Quality Guarantee:
We have got ISO9001 certification
We have CE certificate
We have good technology and experience, we also have the strict Quality Control Department to control the quality
Our Service:
Free sample is available
Special sample according to clients requirement is available
Fastest professional response is for our clients
Delivery Term:
10~35 Days after getting deposit
Payment Term:
L/C (100% L/C at sight)
T/T (30% T/T in advance, 70% balance before delivery)
We have got ISO9001 certification
We have CE certificate
We have good technology and experience, we also have the strict Quality Control Department to control the quality
Our Service:
Free sample is available
Special sample according to clients requirement is available
Fastest professional response is for our clients
Delivery Term:
10~35 Days after getting deposit
Payment Term:
L/C (100% L/C at sight)
T/T (30% T/T in advance, 70% balance before delivery)
Product Packaging
FAQ:
-When can I get the price?
We usually quote within 24 hours after we get your inquiry. If you are very urgent to get the price. Please call us or tell us in
your email so that we will regard your inquiry priority.
-How can I get a sample to check your quality?
After price confirmation, you can require for free sample to check our quality. Normally it takes one week to make a sample. We only provide 1 pc free sample. More samples need to be paid. And the clients need to pay the sample freight cost.
-How can I pay the sample fee and freight cost?
T/T or West Union is available.
-Can you design for us?
OEM is available.
-What is the lead time?
It depends on the order quantity and the season you place the order. The normal delivery time is about 10-35 days.
-How about I had never buy product from China?
We’ll guide you step by step, we can help to calculate all the possible cost for you. Our shipping forwarder will also insist you on your port side.
We usually quote within 24 hours after we get your inquiry. If you are very urgent to get the price. Please call us or tell us in
your email so that we will regard your inquiry priority.
-How can I get a sample to check your quality?
After price confirmation, you can require for free sample to check our quality. Normally it takes one week to make a sample. We only provide 1 pc free sample. More samples need to be paid. And the clients need to pay the sample freight cost.
-How can I pay the sample fee and freight cost?
T/T or West Union is available.
-Can you design for us?
OEM is available.
-What is the lead time?
It depends on the order quantity and the season you place the order. The normal delivery time is about 10-35 days.
-How about I had never buy product from China?
We’ll guide you step by step, we can help to calculate all the possible cost for you. Our shipping forwarder will also insist you on your port side.
